Performance
Print Method
Thermal Direct Print
Supported text and graphics
Word, Graphics,Characters,Barcodes,1D,2D
Print Speed
60mm/s
Baud Rate
9600 default
Resolution
203dpi384dot/line
Paper Type
Thermal Paper
Service Life
50KM
Support OS
Windows、linux、Android
Paper Standard
58mm±0.05mm（W）0.05~0.1mm（thickness）
Print Width
48mm
Max diameter of paper roll
≤30mm
Support language
Default language
language
Mapping number
English description
Chinese
936
Chinese_PRC
Customizable (need to re burn font) 25 day cycle
Japanese
932
Japanese
Korean_Wansung
949
Korean_Wansung
Customizable (need to re burn font) 25 day cycle
Kannada
--
--
Hindi
--
--
Burmese
--
--
Customizable (set software tools) 2-day cycle
Attachment
Physical
Paper Cut
By hand
Operating environment
Temperature：-10°C~50°C；Humidity：20%~80%
Storage environment
Temperature：15°C~20°C；Humidity：45%~75%
Interface
USB/RS232/TTL（3 in1 ）
Host Size
82*58*44mm
Installation size
78*53*43mm
Weight
108g
Power adapter
5~9V/12V
Remark
XP/Win7/Win8/WIN10 Using USB interface Driver printing ，XP/Win7/Win8/WIN10 Serial Port offering SDK；USB and Serial port of Android offering SDK and tech supporting ，LINUX offering SDK and teching support。
